Bosch ConnectModule Retrofit Kit 2022 (BCM3100)

The Bosch ConnectModule (BCM3100) retrofit kit is an e-bike GPS tracker for e-bikes with Bosch Smart System drive. Thanks to the ConnectModule, the e-bike can be located precisely at the latitude and longitude. This way, you always stay informed about where your beloved e-bike is. In addition, the ConnectModule is an e-bike alarm system, which triggers a signal in case of minor shaking and sends an alarm as well as a PushUp message via the eBike flow app in case of severe movements.

Features of the Bosch ConnectModule (BCM3100) retrofit kit - GPS Tracker:

• Bike GPS Tracker
• Only for e-bikes with Bosch Smart System motor (MY 2022 and later).
• simple plug-n-play installation on the motor
• accurate location transmission in the eBike Flow app
• theft detection & audible alarm system
• own, integrated battery

Note on compatibility:

1. If you are unsure whether your motor cover is suitable to fit a ConnectModule in, please contact your ebike manufacturer or ebike seller.
2.  With CUBE e-bikes: On many Cube electric bike models, there is not enough space under the motor cover for installation. Cube has developed suitable replacement motor covers for this, which must be changed before installing the Connect Module.

ConnectModule - GPS Tracker & Alarm System

With this new gadget from Bosch, you protect your e-bike from theft or you can locate it in case of accidental theft. For this purpose, the "eBike alarm function" should be switched on or activated in the eBike flow app. When the alarm function is activated, the ConnectModule informs you of suspicious movements. In the event of an unintentional ride, the ConnectModule will sound a two-stage alarm. In case of slight movements, short and deterrent warning tones are emitted, quasi as a warning. In case of further stronger rides, the second alarm level is triggered. Now a loud sound is emitted and GPS tracking is automatically started and a pushup message is sent to you. Since the ConnectModule has its own integrated and self-sufficient battery, the alarm and GPS tracking works even when the e-bike battery is removed. Thus, your e-bike is protected at all times.

Installation of the Bosch ConnectModule in the Smart System drive system

The ConnectModule is integrated in the motor so that it is invisible to others and is connected between the display and the motor. To do this, the first step is to remove the design cover of the motor housing. The holder can then be placed on the drive unit. In the next step, the display cable is detached from the drive unit. The ConnectModule cable supplied is now plugged into the slot that has become free on the motor. The other end of the cable is connected to the ConnectModule in socket 1 and the previously disconnected display cable is plugged into socket 2. After that, the cables should be laid without kinks in the engine compartment. Now the pre-assembled mounting plate of the ConnectModule can be screwed to the Drive Unit using an M4 x 8 screw. In the last step, the design cover of the motor is mounted again.

ATTENTION: the eBike Alarm function in the Bosch eBike Flow app on your smartphone is active exclusively in the following countries:

Europe: Austria, Belgium, Bulgaria, Croatia, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, United Kingdom.

North America: Canada, USA.

Asia-Pacific: Australia, New Zealand.

Africa: South Africa.

Note: The Bosch eBike Flow app can be downloaded free of charge from the Apple App Store or the Google Play Store.
