Haibike Allmtn CF 10 TRN/IQ - 2026 | Pinion E1.12 MGU

7,299.00€ RRP 8,500.00€ (14.13% Saved)

Item number: 10233-002
Manufacturer Part Number: 45612540
EAN: 4054624167485

The Haibike Allmtn CF 10 TRN/IQ 2026 combines high-quality components with a lightweight 29" carbon frame in a stylish dark blue colour. The weight of the e-bike is particularly noticeable on trails, as the bike is more agile when cornering. At the same time, the Haibike Components TheBar +++ handlebar enables precise steering and contributes to optimum control. The Fully E-MTB is powered by the Pinion E1.12 MGU. This drive is an intelligent all-in-one innovation that combines the motor, gearbox and electronic shifting in a single unit. Together with the FIT InTube 800Wh battery, you are dynamically supported and get an impressive range on all your electric bike tours. The FIT Master Node display allows you to keep an eye on all important ride data while riding.

Features of the Haibike Allmtn CF 10 TRN/IQ - 2026

Fully electric mountain bike with FIT system
Pinion E1.12 MGU motor
FIT InTube 800Wh battery
FIT Master Node display
29" carbon frame
TRP Slate T4 aluminium brakes
RockShox Deluxe Select damper
RockShox Psylo Gold RC fork

Comfort & safety of the Haibike Allmtn CF 10 TRN/IQ - 2026

Uneven terrain is no problem for the full-suspension Haibike Allmtn CF 10 TRN/IQ 2026. The RockShox Psylo Gold RC fork together with the RockShox Deluxe Select damper ensures a comfortable ride. Furthermore, the TRP Slate T4 aluminium brakes with their reliable braking power provide the necessary safety. This means you can always brake quickly and safely with the Haibike e-mountainbike in any situation and in any weather.

E-Bike Types:	E-Mountainbike (E-MTB), Fully E-MTB, Light E-MTB
Model year:	2026
Battery capacity:	800 Wh - 899 Wh
Manufacturer:	Haibike
Derailleur/drive type:	Hub gear - belt drive
FIT E-Bike System Integration:	FIT 2.0
Drive system:	Pinion Drive
Pinion Drive System:	Pinion E1.12 MGU
Frame:	29" MTB Fully carbon frame
Fork:	RockShox Psylo Gold RC \| 160mm
Battery:	FIT InTube 800Wh
Gear shift:	Pinion TE1 Trigger
Tyres:	Front: Continental Kryptotal-Fr, Enduro Soft, foldable skin SL, 60-622 \| Rear: Continental Kryptotal-Re, Enduro Casing, 60-584
Brakes:	TRP Slate T4 \| Aluminium
Saddle:	Selle Royal Vivo
Seat post:	Dropper-Post Remote \| Telescope, 34.9 mm, aluminium
Item:	Haibike Allmtn CF 10 TRN/IQ - 2025
Colour:	midnight blue/grey glossy
Stem:	Haibike TheStem++
Display:	FIT Master Node Display
Wheels:	DT Swiss H 1900 Spline, 29", 30 mm, 15x110 mm, Centrelock
Damper:	RockShox Deluxe Select, Air
Maker's ref. no.:	10233-001: 45612530 \| 10233-002: 45612540 \| 10233-003: 45612550 \| 10233-004: 45612560
Material:	Carbon
Spring travel:	Front: 160mm \| Rear: 160mm
Grips:	XLC MTB Grip Set VLG-1751D2
Motor:	Pinion E1.12 MGU
Headset:	Acros BlockLock
Handlebar:	Haibike Components TheBar +++ \| 780 mm
Permissible total weight:	150 kg
Chain:	Gates Carbon Drive Belt CDX, 120T
Charger:	FIT Standard Charger
Brake lever:	Tektro TRP Slate EVO HD-M807-BL
Size:	S = 40cm \| M = 42cm \| L = 44cm \| XL = 49cm
