€4,499.00
On order, delivery date unknown
With the KTM Macina City 820 XL Belt, you’re perfectly equipped for everyday use and leisurely weekend rides. You’ll be supported by the powerful yet quiet Bosch Performance Line CX motor, which offers a natural riding experience and delivers up to 90 Nm of torque. The power comes from the Bosch PowerTube 800Wh battery, which is integrated into the down tube and can be removed. After long rides, it can be quickly recharged to full capacity using the Bosch Standard Charger 4A. You can view all key data while riding on the Bosch Kiox 500 display. Mounted on the handlebars, it shows information such as speed, battery level and the currently selected assistance level. Furthermore, the Macina City 820 XL Belt is fitted with the SHIMANO NEXUS 5-speed hub gear system. This is specially designed for e-bikes and enables particularly smooth and effortless gear changes. In addition, the hub gear system requires less maintenance than a derailleur system. Further advantages of the XL City e-bike include a wider choice of Frame Sizes and a higher permitted total weight.
eBike24 recommends: Thanks to its natural riding feel, practical hub gears and comfortable geometry, the KTM Macina City 820 XL Belt is perfectly suited to rides at leisurely speeds. It provides powerful assistance and is ideal for riders of larger sizes.
Features of the KTM Macina City 820 XL Belt – 2027
- City e-bike with Bosch Smart System
- Bosch Performance Line CX motor (BDU3840)
- Bosch PowerTube 800Wh battery (horizontal)
- Bosch Kiox 500 display
- SHIMANO NEXUS 5-speed in-hub gearbox
- KTM Tour Snap-it 2.0 luggage rack
- SKS B60 CAB City 28" mudguard
- Suntour NCX32-D coil LO suspension fork
- Busch & Müller front and rear lights
- Permissible total weight: 180 kg
| Battery: | Bosch PowerTUBE 800Wh (horizontal) |
|---|---|
| Battery capacity: | 800 Wh - 899 Wh |
| Battery position: | Intube battery / frame integrated |
| Bosch System: | Bosch Performance Line CX from 2025 Smart System |
| Brakes: | Tektro HD-T535 4-piston |
| Carrier: | KTM Tour Snap-It 2.0/Monkeyload child seat + rack clip |
| Cassette: | Gates 28T rear sprocket |
| Chain: | GATES Carbon-Drive CDX Belt 125T |
| Chainguard: | KTM type 10 (BELT) for Bosch BDU38 |
| Chainring: | Gates CDX 46T |
| Charger: | Bosch STANDARD 4A Charger |
| Colour: | MOON ROCK MATT (SILVER+BLACK) |
| Crank set: | KTM E-COMP2 ISIS 170mm Q8 |
| Derailleur/drive type: | Hub gear - belt drive |
| Disc brakes: | Front: Tektro TR-45 2.3mm CL 180 | Rear: Tektro TR-45 2.3mm CL 160 |
| Display: | Bosch KIOX 500 TFT display |
| Drive system: | Bosch drive |
| E-Bike Types: | Urban & City E-Bike |
| Frame: | Macina City Alloy 6061 Belt PT800 Bosch BDU38/T5970 |
| Frame type: | Step-through |
| Front hub: | Shimano Deore M6000 CL 36H 100-5QR |
| Front light: | B&M Briq-S Premium 110Lux |
| Grips: | Ergon GP1 short |
| Handlebar: | Ergotec Lady Town 31.8 690 mm |
| Headset: | Acros AICR internal 1.1/8"–1.5" angle limiter |
| Item: | KTM Macina City 820 XL Belt |
| Item weight: | 30,1 kg |
| Manufacturer: | KTM |
| Model year: | 2027 |
| Motor: | Bosch PERFORMANCE CX BDU3840 |
| Mudguard: | SKS B60 CAB City 28" rear |
| Pedal: | VP-616 alloy trekking pedal with rubber tread |
| Permissible total weight: | 180 kg (e-bike + rider + luggage) |
| Rear hub: | Shimano NEXUS-5E C7000-5D CL 36H 135-10 |
| Rear light: | B&M Toplight 2C |
| Rims: | Front: Ryde Andra29 36H 622x29C | Rear: Ryde Andra29 36H 622x29C |
| Saddle: | Selle Royal Viaggio |
| Saddle clamp: | KTM Line JD-SC99 – 34.9 mm |
| Seat post: | by Schulz G. 2 ST suspension 30.9/350 |
| Shift lever: | Shimano NEXUS 5 Revoshifter / Display |
| Side stand: | KTM 28" adjustable MY2025 |
| Spokes: | Front: DT Alpine II 2.34 black | Rear: DT Alpine II 2.34 black |
| Stem: | Ergotec Swell RE70i, adjustable 0–60° |
| Suspension fork: | Suntour NCX32-D coil LO 63mm (HD) |
| Tyres: | Front: Schwalbe Marathon E-Plus Perf. DualGuard 50-622 Reflex | Rear: Schwalbe Marathon E-Plus Perf. DualGuard 50-622 Reflex |
| e-bike load capacity: | more than 150 kg |
