€3,999.00
Home delivery (Germany) 25/06/2026 - 29/06/2026
Description
The KTM Macina Gran 820 - 2026 combines sophisticated technology with equipment suitable for everyday use and is aimed at anyone looking for a powerful and comfortable e-bike for extended tours and daily commutes. At the centre is the powerful Bosch Performance Line CX motor, which provides up to 100 Nm of torque for superior support in any riding situation - whether in the city, on unpaved paths or on moderate climbs. The Bosch PowerTube 800Wh battery provides the necessary energy and its large capacity enables long distances to be covered. Furthermore, the Bosch Intuvia 100 display shows you all the important data while riding.
Features of the KTM Macina Gran 820 - 2026
- Trekking electric bike with Bosch Smart System
- Bosch Performance Line CX motor
- Up to 100 Nm torque
- Bosch PowerTube 800Wh battery
- Bosch Intuvia 100 display
- Shimano CUES U6000 rear derailleur
- Busch and Müller lighting
Comfort & safety on the KTM Macina Gran 820
For precise and reliable shifting performance, the Macina Gran 820 is equipped with the Shimano CUES U6000 rear derailleur. This is robust and ensures quiet, smooth gear changes on any terrain. When it comes to lighting, the trekking e-bike relies on German manufacturer Busch & Müller. The Myc front light with 50 lux ensures good illumination of the road, while the Toplight 2C rear light increases visibility from behind. In addition, your clothing is reliably protected from splashing water by the SKS A69R PET Trek 28" mudguards on the front and rear wheels.
eBike24 recommends: With its well-balanced overall package, the KTM Macina Gran 820 is a reliable partner for relaxed tours as well as for everyday use - powerful, comfortable and with a clear focus on quality.
Properties
| Battery: | Bosch PowerTUBE 800Wh horizontal |
|---|---|
| Battery capacity: | 800 Wh - 899 Wh |
| Battery position: | Intube battery / frame integrated |
| Bosch System: | Bosch Performance Line CX from 2025 Smart System |
| Brake: | Tektro HD-T390 / E390 2-Piston |
| Carrier: | KTM light60 snap-it 2.0/monkeyload childseat + rack clip |
| Cassette: | Shimano LG400-10 / 11-48 |
| Chain: | Shimano LG500 |
| Chainguard: | KTM type 9 for Bosch BDU38 |
| Chainring: | FSA steel 42T Direct Mount |
| Charger: | Bosch STANDARD Charger 4A |
| Colour: | Green Purple Flip Matt (Silver + Black) | Diamond Black Matt (Grey + Orange) |
| Crank: | KTM E-COMP ISIS 170mm 016 |
| Derailleur/drive type: | Derailleur - chain drive |
| Disc brakes: | Front: Tektro TR-45 2.3mm CL 180 | Rear: Tektro TR-45 2.3mm CL 160 |
| Display: | Bosch INTUVIA 100 LCD display |
| Drive system: | Bosch drive |
| E-Bike Types: | Cross E-Bike, Trekking E-Bike |
| Fork: | Suntour XCM 32 ATB coil 29" NLO 80mm |
| Frame: | Macina Trekking Onroad Alloy 6061 PT800 Bosch BDU38/T5940 |
| Frame type: | Ladies / Trapeze, Mens, Step-through |
| Front hub: | Shimano Deore M5100 CL 32H 100-5QR |
| Front light: | B&M Myc 50Lux |
| Grips: | Ergon GP1 SD |
| Handlebar: | Ergotec Lady Town 31.8 690mm |
| Headset: | Acros AICR internal 1.5"-1.5" |
| Item: | KTM Macina Gran 820 - 2026 |
| Manufacturer: | KTM |
| Model year: | 2026 |
| Motor: | Bosch PERFORMANCE CX BDU3840 | up to 100 Nm |
| Mudguard: | SKS A69R PET Trek 28" rear |
| Note: | The model is supplied with 85 Nm and can be extended by you to up to 100 Nm via the Bosch Flow app. |
| Pedal: | Trekking pedal VP-616 anti-slip |
| Permissible total weight: | 147 kg |
| Rear derailleur: | Shimano CUES U6000-11/10 LG shadow+ |
| Rear hub: | Shimano Deore M6000 CL 32H 135-5QR |
| Rear light: | B&M Toplight 2C |
| Saddle: | Selle Royal Lookin 3D |
| Saddle clamp: | KTM Line JD-SC99 - 34.9mm |
| Seat post: | KTM Line Il dropper 30.9 T:100 |
| Shift lever: | Shimano CUES U6000-10 display |
| Side stand: | KTM 28" adjustable MY2025 |
| Spokes: | Front: DT Champion 2.0 black | Rear: DT Alpine II 2.34 black |
| Stem: | KTM Line adjust. 0-60° ICR |
| Tyres: | Front: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex | Rear: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex |
| Wheels: | Front: Ryde Rival30 32H 622x30C | Rear: Ryde Rival30 32H 622x30C |
