€2,299.00
Home delivery (Germany) 27/10/2026 - 29/10/2026
The KTM Macina Joy – 2027 lives up to its name and brings pure joy to everyday travel. This sleek and elegant trekking e-bike is the perfect choice for commuters and city cyclists looking for a lightweight bike for urban travel and relaxed weekend excursions. A quiet and unobtrusive Bosch motor with 45 Nm of torque provides the necessary boost. Power is supplied by the Bosch CompactTube 400 Wh battery. It is elegantly integrated into the down tube but can be easily removed for charging at home. This lightweight bike also features the tried-and-tested Shimano CUES 9-speed gearshift with LinkGLIDE technology. Comfort is the focus of the Macina Joy. The Suntour NX1 63 mm suspension fork absorbs bumps on cobbled roads with ease. The angle-adjustable stem allows the riding position to be adjusted to the nearest millimetre at any time – from an upright, comfortable position to a sporty one.
Features of the KTM Macina Joy – 2027
- Trekking e-bike with Bosch Smart System
- Bosch motor with up to 45 Nm
- Bosch CompactTube 400Wh (removable)
- Shimano MT200 / MT200 2-piston brakes
- Shimano CUES U4000-9 LG Shadow rear derailleur
- Schwalbe Energizer Active Plus 50-622 Reflex tyres
eBike24 recommends: The KTM Macina Joy is the perfect everyday bike for the city and leisurely rides. It stands out with its sleek design, the quiet Bosch motor and a luggage rack that’s also suitable for carrying children. A well-thought-out, durable choice for your daily journeys.
| Battery: | Bosch CompactTube 400Wh |
|---|---|
| Battery capacity: | 400 Wh - 499 Wh |
| Battery position: | Intube battery / frame integrated |
| Bosch System: | Bosch Hub Line from 2026 Smart System |
| Brake: | Shimano MT200 / MT200 2-piston |
| Carrier: | KTM Tour Snap-It 2.0/Monkeyload child seat + rack clip |
| Cassette: | Shimano LG300-9 / 11-46 LinkGLIDE |
| Chain: | Shimano LG500-9/10/11 |
| Chainguard: | Herrman’s Fuse 42-44T |
| Charger: | Bosch Compact Charger 2A |
| Colour: | Moon Rock Matt | Sage Green Matt |
| Crank: | Samox Crankset 42T 170mm |
| Derailleur/drive type: | Derailleur - chain drive |
| Disc brakes: | Front: Shimano RT10 CL 180 | Rear: Shimano RT26 / 6-bolt 160 |
| Drive system: | Bosch drive |
| E-Bike Types: | Cross E-Bike, Trekking E-Bike |
| Fork: | Suntour NX1 coil LO 63mm |
| Frame: | Macina Trekking HUB AL6061 Bosch BDU30/T7200 |
| Frame type: | Ladies / Trapeze, Mens, Step-through |
| Front hub: | Shimano QC400 CL 32H 100-5QR |
| Front light: | Litemove RLX-100 100Lux down |
| Gearshift stages: | 9-speed |
| Grips: | GRIP ERGON GP10 |
| Handlebar: | KTM Line Rizer20 640mm |
| Headset: | Acros AICR internal 1.5"-1.5" |
| Item: | KTM Macina Joy – 2027 |
| Item weight: | 23,6 kg |
| Manufacturer: | KTM |
| Model year: | 2027 |
| Mudguard: | SKS A55K PET Trek 28" rear |
| Pedal: | VP-616 alloy trekking pedal with rubber tread |
| Permissible total weight: | 142 kg (e-bike + rider + luggage) |
| Rear derailleur: | Shimano CUES U4000-9 LG Shadow |
| Rear hub: | Bosch HUB LINE |
| Rear light: | AXA Juno |
| Rims: | Front: Ryde Rival Sport 32H 622x25C | Rear: Ryde Rival Sport 32H 622x25C |
| Saddle: | KTM LINE TOUR |
| Saddle clamp: | KTM Line JD-SC99 – 31.8 mm |
| Seat post: | KTM Line 27.2/350 |
| Shift lever: | Shimano CUES U4000-9 LG / Display |
| Side stand: | KTM 28" adjustable MY2025 |
| Spokes: | Front: DT Champion 2.0 black | Rear: DT Alpine II 2.34 black |
| Stem: | KTM Line ICR 0–90° adjustment |
| Tyres: | Schwalbe Energizer Active Plus 50-622 Reflex |
