KTM Macina Kapoho Comp - 2026

4,799.00€

Item number: 11484-001
Manufacturer Part Number: 1260014103

The KTM Macina Kapoho Comp - 2026 is a powerful e-MTB for ambitious trail riders who value performance and range. At its core is the robust Macina Kapoho Dimmix CB 160 UDH frame, combined with the high-performance Bosch Performance CX motor and the Bosch PowerTube 800 Wh battery, which guarantees maximum endurance on long rides. The compact Bosch Purion 200 display combines minimalist design with maximum functionality, giving you a clear overview of speed, battery status and assistance levels. For optimal riding comfort and confident control, the RockShox 35 Silver TK fork with 160 mm travel is complemented by the Suntour Tri-Air 3CR shock.

Features of the KTM Macina Kapoho Comp - 2026

KTM Macina Kapoho Comp with Dimmix frame
Bosch Performance CX motor with 100 Nm
Bosch PowerTube 800 Wh battery
Bosch Purion 200 display
RockShox 35 Silver TK fork
Shimano Deore XT M8100-12 SGS Shadow+

eBike24 recommends: The KTM Macina Kapoho Comp - 2026 is the right choice for anyone looking for a solid, powerful and trail-ready e-mountain bike for demanding mountain adventures.

E-Bike Types:	E-Mountainbike (E-MTB), Fully E-MTB
Model year:	2026
Battery capacity:	800 Wh - 899 Wh
Drive system:	Bosch drive
Manufacturer:	KTM
Battery position:	Intube battery / frame integrated
Bosch System:	Bosch Performance Line CX from 2025 Smart System
Frame:	Macina Kapoho Dimmix CB 160 UDH Bosch BDU38/M6270
Fork:	RockShox 35 Silver TK 29" 160mm 15x110
Battery:	Bosch PowerTUBE 800Wh horizontal
Tyres:	Front: Schwalbe Nobby Nic Perf. Folding 65-622 \| Rear: Schwalbe Nobby Nic Perf. Folding 70-584
Saddle:	Selle Italia Model-X Flow
Seat post:	KTM COMP dropper internal 30.9 T:150
Item:	KTM Macina Kapoho Comp - 2026
Colour:	Grey + Dew Silver Matt (Black)
Stem:	KTM TEAM Trail35
Display:	Bosch PURION 200 Display & Remote
Damper:	Suntour Tri-Air 3CR 250x70
Chainring:	FSA steel 36T Direct Mount
Saddle clamp:	KTM TEAM Light CL-FJ21 - 34.9mm
Grips:	Ergon GA20
Motor:	Bosch PERFORMANCE CX BDU3840
Headset:	Acros AICR internal 1.1/8"-1.5" angle lim
Pedal:	MTB pedal flat VPE-527 alloy
Front hub:	Shimano TC500B CL 32H 110-15TA
Rear hub:	Shimano TC600B CL 32H 148-12TA
Handlebar:	KTM COMP Trail35 rizer 15 780mm
Permissible total weight:	125 kg
Crank:	KTM E-TRAIL ISIS 160mm 016
Cassette:	Shimano Deore M6100-12 / 10-51
Rear derailleur:	Shimano Deore XT M8100-12 SGS shadow+
Chain:	Shimano M6100-12
Shift lever:	Shimano Deore M6100-12
Charger:	Bosch STANDARD Charger 4A
Spokes:	Front: DT Champion 2.0 black \| Rear: DT Alpine II 2.34 black
Front wheel:	Ambrosio E30 Trail 32H 622x30TC
Rear wheel:	Ambrosio E35 Trail 32H 584x35TC
Disc brakes:	Front: Shimano RT30 CL 203 \| Rear: Shimano RT30 CL 180
Brake:	Shimano M4100 / MT420 4-Piston
