€3,299.00
On order, delivery date unknown
The KTM Macina Sport SX 20 – 2027 is a dynamic, lightweight trekking e-bike that is perfect for daily commuting and long weekend rides. The compact Bosch Performance Line SX motor delivers up to 60 Nm of torque and provides particularly smooth and quiet assistance. The Bosch CompactTube 400 Wh battery is securely integrated into the frame but can be easily removed for charging. The drive system is controlled via the ergonomic Bosch Purion 200 display, which combines the control unit and a crisp colour screen directly on the handlebar grip. The Shimano CUES 10-speed gearshift provides the necessary range of gear ratios. The key advantage is the LinkGLIDE technology used here. The cassette and chain are heavily reinforced, which minimises wear caused by the motor assistance. Gear changes are always smooth, precise and reliable, even under load.
Features of the KTM Macina Sport SX 20 – 2027
- Trekking e-bike for a wide range of uses
- Bosch Performance SX motor with up to 60 Nm
- Bosch CompactTube 400Wh battery
- Bosch Purion 200 display & remote
- Shimano CUES 10-speed gearshift
- Shimano MT201 / MT200 2-piston brakes
- Suntour NCX 32-D Air LO 63mm fork
eBike24 recommends: The KTM Macina Sport SX 20 is the ideal choice for anyone looking for a zippy and lightweight e-bike for everyday use. The quiet Bosch SX motor and the low-wear Shimano LinkGLIDE gearshift make it an extremely comfortable and durable companion.
| Battery: | Bosch CompactTube 400Wh |
|---|---|
| Battery capacity: | 400 Wh - 499 Wh |
| Battery position: | Intube battery / frame integrated |
| Bosch System: | Bosch Performance Line SX from 2024 Smart System |
| Brake: | Shimano MT201 / MT200 2-piston |
| Carrier: | KTM light 42 snap-it 2.0/monkeyload rack clip |
| Cassette: | Shimano LG400-10 / 11-48 LinkGLIDE |
| Chain: | Shimano LG500-9/10/11 |
| Chainguard: | Horn Catena 22 44T |
| Chainring: | KTM Aluminium 42T Direct Mount |
| Charger: | Bosch Compact Charger 2A |
| Colour: | Matt Platinum Bronze | Dark Sea |
| Crank: | KTM E-TEAM2 ISIS 170mm 08 |
| Derailleur/drive type: | Derailleur - chain drive |
| Disc brakes: | Front: Shimano RT10 CL 180 | Rear: Shimano RT10 CL 160 |
| Display: | Bosch Purion 200 Display & Remote |
| Drive system: | Bosch drive |
| E-Bike Types: | Cross E-Bike, Trekking E-Bike |
| Fork: | Suntour NCX 32-D Air LO 63mm |
| Frame: | Macina Trekking Alloy 6061 CPT400 Bosch SX BDU31/T4110 |
| Frame type: | Ladies / Trapeze, Mens, Step-through |
| Front hub: | Shimano Deore M5100 CL 32H 100-5QR |
| Front light: | Litemove RLX-100 100Lux down |
| Gearshift stages: | 11-speed |
| Grips: | ERGON GS1 |
| Handlebar: | KTM Line low-riser 640mm |
| Headset: | Acros AICR internal 1.5"-1.5" |
| Item: | KTM Macina Sport SX 20 – 2027 |
| Item weight: | 21,5 kg |
| Manufacturer: | KTM |
| Model year: | 2027 |
| Motor: | Bosch Performance SX motor |
| Mudguard: | SKS EVO AL 55mm 28" rear |
| Pedal: | VP-616 alloy trekking pedal with rubber tread |
| Permissible total weight: | 140 kg (e-bike + rider + luggage) |
| Rear derailleur: | Shimano CUES U6000-11/10 LG Shadow+ |
| Rear hub: | Shimano TC500 CL 32H 142-12TA |
| Rear light: | AXA Juno |
| Rims: | Front: Black Jack Ready25 32H 622x25TC | Rear: Black Jack Ready25 32H 622x25TC |
| Saddle: | Selle Royal Vaia Gel |
| Saddle clamp: | KTM Line JD-SC99 – 31.8 mm |
| Seat post: | KTM Line 27.2/350 |
| Shift lever: | Shimano CUES U6000-10 LG / Display |
| Side stand: | KTM 28" adjustable MY2025 |
| Spokes: | Front: DT Champion 2.0 black | Rear: DT Alpine II 2.34 black |
| Stem: | KTM Line ICR 0–90° adjustment |
| Tyres: | Schwalbe G-One Overland Eco 45-622 |
