€4,299.00
Home delivery (Germany) 22/12/2026 - 24/12/2026
The KTM Macina Sport SX Elite is a modern trekking e-bike designed for low weight and extremely high riding comfort. It is powered by the Bosch Performance SX motor, which, in combination with the removable Bosch CompactTube 400 Wh battery, offers dynamic yet smooth assistance. The lightweight Macina Trekking On Premium Carbon frame ensures high stiffness whilst keeping the overall weight down. Combined with the Suntour NCX32-D Air suspension fork (63 mm travel), this results in a comfortable and stable ride with efficient damping of bumps. The drive system is controlled via the Bosch Purion 200 display, which includes a remote control unit; this clearly displays all relevant riding data and allows for intuitive adjustment of the assistance levels. A technical highlight is the Shimano CUES Di2 11-speed gearshift. This electronic system enables precise, fast and load-independent gear changes, whilst offering low maintenance requirements and high reliability.
Features of the KTM Macina Sport SX Elite – 2027:
- 28-inch carbon trekking frame
- Bosch Performance SX motor
- Bosch CompactTube 400 Wh battery (removable)
- Bosch Purion 200 display & remote
- Suntour NCX32-D Air LO suspension fork (63 mm)
- Litemove SEC-160 front light (160 lux)
- Schwalbe G-One Overland 45-622 tyres
eBike24 recommends:
The KTM Macina Sport SX Elite combines powerful drive technology with a high level of riding comfort and is ideal for everyday use as well as challenging tours. The perfect trekking e-bike, whatever your age!
| Battery: | Bosch CompactTUBE 400Wh |
|---|---|
| Battery capacity: | 400 Wh - 499 Wh |
| Battery position: | Intube battery / frame integrated |
| Bosch System: | Bosch Performance Line SX from 2024 Smart System |
| Brakes: | Shimano MT420-3A/MT410 2-piston |
| Cassette: | Shimano LG400-11 / 11-50 LinkGLIDE |
| Chain: | KMC eGLIDE LG |
| Derailleur/drive type: | electr. derailleur - chain drive |
| Display: | Bosch PURION 200 Display & Remote |
| Drive system: | Bosch drive |
| E-Bike Types: | Cross E-Bike, Trekking E-Bike |
| Frame: | 28" Macina Trekking PREMIUM CARBON |
| Frame type: | Ladies / Trapeze, Mens, Step-through |
| Front light: | Litemove SC-160 160Lux |
| Gear shift: | Shimano CUES Di2 U8050-11LG Shadow |
| Gearshift stages: | 11-speed |
| Handlebar: | KTM TEAM II low-riser 640mm |
| Item weight: | 19,2 kg |
| Manufacturer: | KTM |
| Model year: | 2027 |
| Motor: | Bosch PERFORMANCE SX BDU3144 – 60 Nm |
| Mudguard: | SKS EVO AL 55mm 28" rear |
| Pedal: | VP-616 alloy trekking pedal with rubber tread |
| Permissible total weight: | 130 kg (e-bike + rider + luggage) |
| Rear light: | AXA Juno |
| Saddle: | Selle Royal Vaia Gel |
| Side stand: | Hebie 28" adjustable |
| Suspension fork: | Suntour NCX32-D SPORT Air LO 63mm 15x100 |
| Tyres: | Schwalbe G-One Overland Eco 45-622 |
