Litemove RXW-2900 e-bike headlight

The Litemove RXW-2900 E-Bike Headlight gives you excellent visibility in road traffic. With a light output of up to 2900 lumens (when the high beam is activated) it brightly illuminates your route while making you clearly visible to other road users. In addition, the front light offers daytime running light, low beam and high beam modes. The built-in light sensor automatically switches between daytime running light and low beam while riding. The high beam is controlled via the high-beam button on the handlebar. The RXW-2900 headlight is mounted to the handlebar using the supplied Litemove lamp bracket.

Important note: The headlight is supplied with a cable with open ends. This cable must be prepared for fitting to specific e-bike systems. The required connection cable must be purchased separately. Suitable brackets and light cables can be found in our light cable category.

Features of the Litemove RXW-2900 E-Bike Headlight

• Headlight with up to 2900 lumens output
• Daytime running light, low beam & high beam
• Road traffic certified (StVZO)
• Protection class IP56 (protected against dust & water jets)
• Litemove RXW-2900 headlight including cable & high-beam button
• 1x lamp bracket for handlebar

How to set the desired watt mode

To set the desired watt mode, first switch the light on. Then press and hold the auto-sensor switch on the rear of the headlight for about five seconds until the status LED starts to flash. After releasing the button, briefly press the flashing switch to select the desired high-beam power mode. You can choose between the green mode (17 W), the yellow mode (22 W) and the red mode (28 W). Once you have selected the desired mode, wait until the flashing becomes steady after a few seconds; the setting is then complete.

Warning: The manufacturer recommends a minimum of 17 W at a nominal voltage of 12 V for optimal high-beam performance and warns that insufficient power supply can affect performance. Some motor systems, such as Bosch 5 Gen, for example, may only support the 17 W mode.
