€6,499.00
Home delivery (Germany) 30/04/2026 - 05/05/2026
Description
The Winora Sinus AS 2026 is the ideal trekking eBike for leisurely bike tours and city traffic. The 27.5" aluminium frame has Low entry, which makes getting on the eBike particularly easy. Furthermore, the matt black paintwork gives the Winora bike a modern and elegant look. The drive is provided by the powerful Pinion E1.9 MGU motor. This intelligent all-in-one innovation combines the manual gearbox and the electronic gearstick in 1 unit. At the same time, the associated FIT Tubepack 800Wh provides you with sufficient power. This means you are always powerfully supported and have an impressive range available on all your tours. While riding, you can keep an eye on all data such as speed, distance and battery status via the FIT Display Comfort .
Features of the Winora Sinus AS - 2026
- Trekking eBike with FIT system
- Pinion E1.9 MGU motor
- FIT Tubepack 800Wh battery
- FIT Display Comfort
- 27.5" aluminium frame
- SR Suntour Mobie34 DS fork
- Ergo Sport handlebars with Herrmans Single Lock grips
- Magura MT-C brakes
Safety & comfort on the Winora Sinus AS - 2026
The Magura MT-C brakes provide the necessary safety on the Winora Sinus AS 2026. They allow you to brake quickly and safely in any situation. Should you ever find yourself travelling on uneven terrain, the trekking eBike is also cushioned by the SR Suntour Mobie34 DS fork . Together with the Herrmans Single Lock grips , the Ergo Sport handlebar offers optimum grip and comfort, even on longer rides. The Litemove AC-210S headlight and Supernova TL3 Z rear light ensure safety on the road. This means you are always clearly visible in all visibility conditions.
Properties
| Battery: | FIT Tubepack 800Wh |
|---|---|
| Battery capacity: | 800 Wh - 899 Wh |
| Brake: | Magura MT-C | Aluminium |
| Carrier: | Front: Front Carrier Aluminium | Rear: System carrier, MIK HD |
| Charger: | Pinion charger |
| Colour: | black matte |
| Derailleur/drive type: | Hub gear - belt drive |
| Display: | FIT Display Comfort |
| Drive system: | Pinion Drive |
| E-Bike Types: | Cross E-Bike, Trekking E-Bike, Urban & City E-Bike |
| FIT E-Bike System Integration: | FIT 2.0 |
| Fork: | SR Suntour Mobie34 DS | Air, 80mm |
| Frame: | 27.5" aluminium frame |
| Frame type: | Step-through |
| Grips: | Herrmans Single Lock handles |
| Handlebar: | Ergo Sport | 680 mm |
| Headlights: | Litemove AC-210S, 210 lux |
| Headset: | A-Head Tapered |
| Item: | Winora Sinus AS - 2026 |
| Maker's ref. no.: | 10247-001: 44516530 | 10247-002: 44516540 | 10247-003: 44516550 |
| Manufacturer: | Winora |
| Material: | Aluminium |
| Model year: | 2026 |
| Motor: | Pinion E1.9 MGU |
| Mudguard: | Curana Orbit 65, aluminium |
| Permissible total weight: | 180 kg |
| Pinion Drive System: | Pinion E1.9 MGU |
| Rear light: | Supernova TL3 Z |
| Saddle: | Selle Royal Lift |
| Size: | 10247-001: S = 43cm | 10247-002: M = 49cm | 10247-003: L = 55cm |
| Spring travel: | Front: 80mm |
| Stand: | Ursus Mooi, adjustable |
| Stem: | Satori adjustable |
| Tyres: | Schwalbe Al Grounder Performance | 60-584, reflective stripes |
