Winora Sinus AS - 2025 | Low entry | Pinion E1.9 MGU

6,499.00€

Item number: 10247-001
Manufacturer Part Number: 44516530
EAN: 4054624169243

The Winora Sinus AS 2025 is the ideal trekking eBike for leisurely bike tours and city traffic. The 27.5" aluminium frame has Low entry, which makes getting on the eBike particularly easy. Furthermore, the matt black paintwork gives the Winora bike a modern and elegant look. The drive is provided by the powerful Pinion E1.9 MGU motor. This intelligent all-in-one innovation combines the manual gearbox and the electronic gearstick in 1 unit. At the same time, the associated FIT Tubepack 800Wh provides you with sufficient power. This means you are always powerfully supported and have an impressive range available on all your tours. While riding, you can keep an eye on all data such as speed, distance and battery status via the FIT Display Comfort .

Features of the Winora Sinus AS - 2025

Trekking eBike with FIT system
Pinion E1.9 MGU motor
FIT Tubepack 800Wh battery
FIT Display Comfort
27.5" aluminium frame
SR Suntour Mobie34 DS fork
Ergo Sport handlebars with Herrmans Single Lock grips
Magura MT-C brakes

Safety & comfort on the Winora Sinus AS - 2025

The Magura MT-C brakes provide the necessary safety on the Winora Sinus AS 2025. They allow you to brake quickly and safely in any situation. Should you ever find yourself travelling on uneven terrain, the trekking eBike is also cushioned by the SR Suntour Mobie34 DS fork . Together with the Herrmans Single Lock grips , the Ergo Sport handlebar offers optimum grip and comfort, even on longer rides. The Litemove AC-210S headlight and Supernova TL3 Z rear light ensure safety on the road. This means you are always clearly visible in all visibility conditions.

Specifications

E-Bike Types:	Cross e-Bikes, Trekking e-Bikes, Urban & City e-Bikes
Model year:	2025
Battery capacity:	800 Wh - 899 Wh
Frame type:	Low-entry / Wave
Derailleur/drive type:	Hub gear - belt drive
FIT E-Bike System Integration:	FIT 2.0
Drive system:	Pinion Drive
Manufacturer:	Winora
Pinion Drive System:	Pinion E1.9 MGU
Frame:	27.5" aluminium frame
Fork:	SR Suntour Mobie34 DS \| Air, 80mm
Battery:	FIT Tubepack 800Wh
Tyres:	Schwalbe Al Grounder Performance \| 60-584, reflective stripes
Saddle:	Selle Royal Lift
Carrier:	Front: Front Carrier Aluminium \| Rear: System carrier, MIK HD
Item:	Winora Sinus AS - 2025
Colour:	black matte
Headlights:	Litemove AC-210S, 210 lux
Stem:	Satori adjustable
Display:	FIT Display Comfort
Maker's ref. no.:	10247-001: 44516530 \| 10247-002: 44516540 \| 10247-003: 44516550
Mudguard:	Curana Orbit 65, aluminium
Material:	Aluminium
Spring travel:	Front: 80mm
Grips:	Herrmans Single Lock handles
Motor:	Pinion E1.9 MGU
Headset:	A-Head Tapered
Rear light:	Supernova TL3 Z
Handlebar:	Ergo Sport \| 680 mm
Permissible total weight:	150 kg
Charger:	Pinion charger
Stand:	Ursus Mooi, adjustable
Size:	10247-001: S = 43cm \| 10247-002: M = 49cm \| 10247-003: L = 55cm
Brake:	Magura MT-C \| Aluminium
