Orbea seat post with rear light 27.2mm diameter, 350mm length

64.99€

Item number: 10118
Manufacturer Part Number: X127

Delivery time to Germany 1-2 business days

Original Orbea seat post with integrated rear light for connection to the battery. The stylish... more

Original Orbea seat post with integrated rear light for connection to the battery. The stylish seatpost from Orbea ensures perfect integration of the rear light into your eBike. It is integrated directly into the seat post. With 30 lumens, the rear light is sufficiently bright and also fulfils the requirements of the German Road Traffic Licensing Regulations. Particularly practical: the seat post with rear light can be connected directly to the eBike system. This eliminates the need to charge the rear light separately and you are always safe on the road.

Features of the Orbea seat post with rear light

30 lumen German Road Traffic Licensing Regulations rear light
Fully integrated into the seat post
Connection to eBike battery/motor
6 - 16 V DC voltage
Supplied with JST plug for Mahle
27.2 mm diameter & 350 mm length

Notes on mounting the Orbea seatpost rear light

The seat post is supplied from the factory with a JST connector. This allows the rear light to be connected to Orbea eBikes with Mahle drive and the matching light cable. Without this special connector, however, the seat post can be connected to any power source with a 6 - 16 V DC voltage.

Drive system:	Bafang drive, Bosch drive, Brose drive, Fazua drive, FlyOn drive, Giant drive, Impulse drive, Mahle Drive, Panasonic drive, Shimano drive, TQ drive, Yamaha drive
Supply voltage :	6 V, 12 V, > 12 V
Light mounting position:	Seatpost
Manufacturer:	Orbea
Power source:	eBike battery
Max. power consumption:	up to 3 W
Item:	Orbea seat post with rear light
Scope of delivery:	Orbea seat post with rear light with JST connection cable
Colour:	black
Maker's ref. no.:	X127
Diameter:	27.2 mm
Material:	Aluminium
Light output:	30 lumen
Operating voltage:	6 - 16 V
Length:	350 mm
Light sources:	LED
StVZO approval:	Yes

Features of the Orbea seat post with rear light

Notes on mounting the Orbea seatpost rear light

Orbea eBikes equipped with the seatpost ex works
