KTM Macina Aera 772 LFC 2024

KTM Macina Aera 772 LFC 2024
4,599.00€

Prices incl. VAT plus shipping costs

  • 8294-001
  • 1230086503 / 023343503
  • 9008594471788

Frame Size:

With the KTM Macina Aera 772 LFC you get a comfortable as well as sporty city SUV with off-road MTB equipment. Thanks to Suntour XCR 34 suspension fork with 80 mm travel, Shimano Deore gears and thick Schwalbe Johnny Watts tires, you can easily break out of the urban routine and let off steam even on rough terrain. A Bosch Smart System drive with 85 Nm of torque and a 750 Wh Akkuk provide constant thrust. In addition, the Aera 772 LFC comes with mudguards, Litemove lighting system and Racktime rack with pannier holder. Thus, one is well equipped for extra long weekend tours with luggage.

Features of the KTM Macina Aera 772 LFC - 2024:

  • 27.5 inch Macina MTB low entry frame aluminum frame.
  • Bosch Performance CX Smart System drive, 85 Nm
  • Bosch Powertube 750 Wh battery
  • Bosch Kiox 300 Display + LED Remote
  • Shimano Deore M5130 10-speed gears
  • Suntour XCR 34 air suspension fork 80 mm travel
  • Racktime luggage rack, Litemove lighting system, Ergon grips and much more.
  • Swallow Johnny Watts performance tires 65-584 DD

Ebike24 recommends: The KTM Macina Aera 772 the perfect partner for the city as well as for trips in nature. With the Aera 772 LFC you get an SUV e-bike, which is thanks to high-quality eMTB equipment and the latest Bosch technology for every use.

Specifications
E-Bike Types: E-Mountainbike (e-MTB), SUV E-Bike, Trekking e-Bikes
Model year: 2023
Battery capacity: 700 Wh - 799 Wh
Drive system: Bosch drive
Manufacturer: KTM
Frame type: Low-entry / Wave
Derailleur/drive type: Derailleur - chain drive
Bosch System: Bosch Performance Line CX from 2022 Smart System
Battery position: Intube battery / frame integrated
Frame: Macina Trekking Onroad Aluminum 6061 PT750Wh Bosch Gen.4 / T-2940
Fork: Suntour XCR 34 Air 27.5" LOR 80mm 15x110 taper
Battery: Bosch PowerTube 750 Wh Smart System horizontal
Tyres: Schwalbe Johnny Watts Perf. Folding 65-584 DD
Saddle: Selle Royal Lookin+
Seat post: KTM Team 30.9/300
Carrier: Alumee light (snap-it 2.0)
Item: KTM Macina Aera 772 LFC 2024
Colour: Machine Grey (black+silver)
Model year: 2024
Stem: KTM Line adjust. 0-60° internal
Display: Bosch Kiox 300
Side stand: KTM 28" adjustable
Wheels: front: KTM Line - Shimano MT410B CL 32H 110-15TA Ryde Rival30 32H 584x30C DT Champion 2.0 black | rear: KTM Line - Shimano Deore M6000 CL 32H 135-5QR Ryde Rival30 32H 584x30C DT Alpine II 2.34 black
Mudguard: Racktime Alu 72mm
Spring travel: 80 mm
Grips: Ergon GP1 SD
Motor: Bosch Performance CX Gen.4 Smart System - 85 Nm
Headset: Acros AICR internal 1.1/8"-1.5" angle limit
Rear light: B&M Xeltec integrated in the Fender
Front light: Litemove SE-150 LED 150Lux
Pedal: MTB-Pedal flat VPE-527 Aluminum
Wheel size: 27,5"
Handlebar: KTM Team rizer15 680mm
Permissible total weight: 147 kg
Crank: KTM E-COMP ISIS 170mm Q16
Cassette: Shimano LG400-10 / 11-43
Rear derailleur: Shimano Deore M5130-10 LG shadow+
Chain: Shimano LG500
Shift lever: Shimano Deore M5130-10 display
Charger: Bosch Smart System Standard Charger - 4A
Disc brakes: Tektro TR-45 2.3mm CL 180 / 180
Control unit: Bosch LED Remote
Brake: Tektro HD-M535 4-Piston
GPS: No - Bosch ConnectModule Ready
