- Order number: 6079-001
- Manufacturer Part Number: 10020
- EAN 4260495060088
The EBV - E-Bike Battery down tube battery is specially made for e-bikes with 36V Bosch Classic Line drive. The latest 2.0 generation of the e-bike battery guarantees intelligent cell balancing for a long service life and an even more powerful battery management system.
The e-bike battery comes with two capacity sizes. The 468 Wh with 13 Ah already offers more capacity than the original from Bosch and is ideal for city rides or weekend excursions. With 612 Wh and 17Ah, you get a real long-running variant, which also supports you over long distances of up to 130 km. Compatibility with the Bosch Classic Line drive system means that the original Bosch Classic Line charging cable can still be used for charging. The lithium-ion batteries from EBV have no memory effect and can be charged at any time, regardless of the state of charge. The charging time is a maximum of 2.5 hours for full capacity (at 468 Wh (at 612 Wh approx. 3.5h).
Features of the E-Bike Vision down tube battery:
- downtube / frame battery for 36 V Bosch Classic Line drive system.
- Generation 2.0 - even more powerful battery management system.
- Two variants:
13 Ah / 468 Wh - 10S5P - Samsung INR18650-26H
17 Ah / 612 Wh - 10S5P - Samsung INR18650-35E
- Integrated charging socket for quick charging directly on the bike in conjunction with the optionally available 6 A quick charger (36 V)
- compatible with original 36 V Bosch charger
- Splash-proof and dust-tight
- Intelligent cell balancing, for a long service life
- approx. 3.0 kg light
- Made in Europe
- UN certified
Compatibility of the EBV battery for Bosch Classic Line
The E-Bike Vision downtube / frame battery for Bosch Classic Line is compatible with any Bosch e-bike of the model years 2010, 2011, 2012 and 2013, as well as Classic Line models from 2014 with downtube frame battery. The battery is only suitable for down tube mounting.
The Bosch Classic-Line down tube e-bike battery fits all Bosch electric bike brands:
Bergamont, Blue Label, Cannondale, Centurion, Focus, Göricke, Haibike, Hercules, Kalkhoff, Kreidler, KTM, Merida, Panther, Raleigh, Riese &, Müller, Rotwild, Scott, Sinus, Stevens, Univega, Victoria, VSF Fahrradmanufaktur etc.
|Bosch System:||Bosch Classic Plus Line|
|Battery capacity:||400 Wh - 499 Wh, 600 Wh - 699 Wh|
|Drive system:||Bosch drive|
|Scope of delivery:||1x replacement battery for Bosch Classic Line|
|Compatibility:||2010,2011,2012,2013, various Classic Line models from 2014|
