KTM Macina Multi CX 2024

KTM Macina Multi CX 2024

Prices incl. VAT plus shipping costs

  • 8292
  • 1230212506
  • 9008594475069

Delivery time to Germany 5 - 6 weeks

Show 2 related & instantly available E-Bikes
With the KTM Macina Multi CX , the name says it all. This all-rounder is a versatile e-load... more

With the KTM Macina Multi CX, the name says it all. This all-rounder is a versatile e-load bike and is ideal as a family carriage or as an e-transporter for companies. Thanks to a massive heavy load luggage carrier, the Multi CX can transport up to 170 kg payload. Furthermore, it is expandable with many different features, such as a child seat for the little ones, a Eurobox for goods or all kinds of panniers for a long e-bike trip. In addition, the latest Bosch technology, with 85 Nm of torque and an enduring 725 Wh battery, ensures a pleasant ride, even under heavy load.

Features of the KTM Macina Multi CX - 2024:

  • 24" KTM Multi alloy aluminum frame.
  • Bosch Performance Line Smart System drive, 85 Nm
  • Bosch PowerPack 725 Wh battery pack
  • Bosch LED-Remote Smart System
  • Maximum payload 170 kg payload
  • 5-speed Shimano Nexus with Gates belt drive
  • Busch & Müller lighting system
  • Racktime Snap-It 2.0 luggage rack + Heavy Load
  • Conti Air King 60-507 Reflex tires

Ebike24 recommends: The KTM Macina Multi CX is recommended for riders who want to get from A to B quickly with heavy loads. Whether as a family transporter for trips to daycare and then to the bulk purchase or as a company car for companies to do small transports emission-free.

E-Bike Types: Cargo E-Bikes, Compact & Folding E-Bikes, Urban & City e-Bikes
Model year: 2023
Battery capacity: 700 Wh - 799 Wh
Drive system: Bosch drive
Manufacturer: KTM
Frame type: Unisex
Derailleur/drive type: Hub gear - belt drive
Bosch System: Bosch Performance Line CX from 2022 Smart System
Battery position: Seat tube battery / semi-integrated
Frame: Macina Multi CX 24" Aluminum 6061 Si-PP800Wh Bosch Gen.4 / C-3020
Fork: 24" Aluminum cargo
Battery: Bosch PowerPack 725 Wh Smart System
Tyres: Schwalbe Pickup SuperDefense 60-507
Saddle: Selle Royal Essenza EPTech
Seat post: KTM Comp 34.9 / 350
Carrier: Multi front & Multi rear (snap it 2.0) & 6 straps
Item: KTM Macina Multi CX 2024
Colour: Machine Grey matt (silver+orange)
Model year: 2024
Stem: Ergotec HighCarisma 50
Display: Bosch LED remote Smart System
Side stand: Ursus Jumbo EVO Zweibeinständer
Wheels: front: KTM Line - Shimano Deore M6010 CL 36H 100-15TA Ryde Andra29 36H 507x29C DT Alpine II 2.34 black | rear: KTM Line - Shimano Nexus 5 Disc CL 36H 135-10 Ryde Andra29 36H 507x29C DT Alpine II 2.34 black
Mudguard: SKS C66R 66mm black matt
Grips: Ergon GP1 short ohne Barend
Motor: Bosch Performance CX Gen.4 Smart System - 85 Nm
Headset: Acros AICR internal 1.1/8"-1.5" angle limit
Rear light: B&M Type 340 brex LED
Front light: B&M Lumotec IQ-XS LED 80Lux
Pedal: Trekking-Pedal VP-616 anti-slip
Wheel size: 24"
Handlebar: Ergotec Riserbar 50 -780mm
Permissible total weight: 152 kg
Crank: KTM E-LINE BNI 170mm Q16
Cassette: Gates rear-sprocket 34T Nexus 5
Rear derailleur: Shimano Nexus 5-Speed hub shifter
Chain: Gates Carbon Drive 174T CDX belt
Shift lever: Shimano Nexus 5 Revoshifter
Charger: Bosch Smart System Standard Charger - 4A
Disc brakes: Shimano RT54 CL 180 / EM300 CL 180
Brake: Shimano MT402 (3-F) / MT420 4-Piston
GPS: No - Bosch ConnectModule Ready
