Tern Orox S12 27.5" - 2024


Prices incl. VAT plus shipping costs

  • 10050-001
  • 810067161732

Frame Size:

No adventure is too big for the Tern Orox S12 27.5" - whether it's a family trip to the... more

No adventure is too big for the Tern Orox S12 27.5" - whether it's a family trip to the beach, cycling to remote locations or trail action with luggage. The Tern Orox combines the two worlds: Cargo bike and mountain bike. It can therefore be described as an e-MTB cargo bike like no other eBike. The 27.5" version also comes with extra-wide 4" fat bike tyres. In total, the Orox S12 with its Bosch Performance Line CX motor can move up to 210 kilograms. There is plenty of space for luggage and equipment or even children on the matching accessories. The Shimano XT 12-speed gears and Magura MT5 disc brakes provide the necessary control in every situation.

Features of the Tern Orox S12 27.5"

  • Unique e-cargo mountain bike
  • Bosch Performance Line CX Smart System with 85 Nm
  • 800 Wh PowerPack battery expandable by 800 Wh
  • Permissible total weight 210 kg & 180 kg on the trail
  • 4 inch (>10 cm) Schwalbe Johnny Watts tyres
  • Shimano Deore XT 12-speed gears

eBike24 recommends: The Tern Orox S12 27.5" with fat bike tyres is perfect for anyone with a strong thirst for adventure - even off the beaten track.

E-Bike Types: Cargo E-Bikes, E-Fatbike, E-Mountainbike (e-MTB), Hardtail E-MTB, SUV E-Bike
Manufacturer: Tern
Battery position: Down tube battery / semi-integrated, Seat tube battery / semi-integrated
Battery option: Dual Battery compatible
Bosch System: Bosch Performance Line CX from 2022 Smart System
e-bike load capacity: more than 150 kg
Derailleur/drive type: Derailleur - chain drive
Frame type: Unisex
Drive system: Bosch drive
Battery capacity: 800 Wh - 899 Wh, Dual Battery compatible
Model year: 2024
Frame: Tern Orox - Aluminium
Fork: Atlas X
Battery: Bosch PowerPack 800 Wh
Tyres: Schwalbe Johnny Watts 27.5" x 4"
Saddle: Ergon SM, E-Mountain Sport
Seat post: Syntace P6 AL7050, 34.9 mm
Carrier: Atlas X loadable up to 100 kg
Weight: Size M: approx. 33.2 kg
Item: Tern Orox S12 27.5" - 2024
Colour: satin pine green
Stem: Level Nine, 45 mm (M), 65 mm (L)
Display: Bosch Kiox 300
Mudguard: Aluminium heavy duty mudguards
Saddle clamp: 34.9 mm
Grips: Ergon
Rims: Tern Atlas X
Motor: Bosch Performance Line CX Smart System - 85 Nm
Rear light: LED rear light with brake light
Front light: Ignis Headlight, Ultra wide 700 Lumen
Pedal: MTB pedals
Front hub: Tern Atlas X, Boost Thru-Axle with integrated Tern tool
Rear hub: Tern Atlas X, Boost Thru-Axle, Syntace X-12 standard
Wheel size: 27.5"
Handlebar: Level Nine, AL-7050, 800 mm
Permissible total weight: 210 kg / 180 kg for off-road use
Crank: Tern Orox
Cassette: Shimano 10-51T
Rear derailleur: Shimano Deore XT Shadow+ 12-speed
Chain: KMC 12 spd eBike chain
Shift lever: Shimano Deore
Charger: Bosch Standard Charger 4A
Stand: Atlas Kickstand XL
Brake lever: Magura MT5
StVZO approval: Yes
Battery capacity: 800 Wh with DualBattery up to 1,600 Wh
Disc brakes: 203 mm
Control unit: Bosch LED Remote
Brake: Magura MT5 4-piston disc brake
GPS: yes - Bosch ConnectModule
Bosch E-Bike System: Bosch Smart System
