Description
The Shimano STEPS in‑tube battery BT‑E8036 offers a 630 Wh capacity, making it ideal for longer mountain‑bike tours. Thanks to the 1st‑generation battery management technology, the battery delivers not only strong performance but also an excellent service life. Even after 1,000 charging cycles, the BT‑E8036 still retains at least 60% of its total capacity.
LED indicators provide information about the current charge status. These LEDs also communicate an error signal should a system fault occur. In addition, the battery features an ON/OFF switch directly on the housing.
Thanks to the in‑tube design, the battery is fully integrated into the down tube and is therefore well protected from external influences by the frame cover. Charging is possible either while installed on the bike via the EW‑CP100 charging port or externally. Battery removal is also straightforward and quick, simply by turning the key.
The battery is compatible with the existing chargers EC‑E6000, EC‑E6002 and EC‑E8004. When used with the EC‑E8004 charger, the lithium‑ion cells are fully charged in approximately 6 hours, with 50% charge reached in around 2.5 hours. The required SM‑BTE80 adapter is necessary.
Please note: The Shimano BT‑E8036 battery is exclusively compatible with the Shimano drive systems EP800, E8000, E7000, E6000 and E5000 and cannot be used with the EP801 or EP600 drive units. For EP801 and EP600 systems, you will need the Shimano BT‑EN806 630 Wh battery.
Features of the Shimano STEPS BT‑E8036 – 630 Wh
- 1st generation battery management technology
- In‑tube lithium‑ion battery for down‑tube installation
- Part of the SHIMANO STEPS E8000 series
- Extremely long service life
- LED charge indicator
- ON/OFF switch
- 630 Wh capacity
- 36 V
- 17.5 Ah
- Weight: approx. 3.7 kg
- Dimensions: 42 cm x 8.3 cm x 6.5 cm
Properties
| Battery capacity: | 600 Wh - 699 Wh |
|---|---|
| Battery type: | Li-Ion |
| Capacity: | 17.5 Ah |
| Charger: | EC-E6000 | EC-E6002 | EC-E8004 |
| Charging cycles: | After 1,000 charging cycles remaining capacity of approx. 60% |
| Charging time: | 6h - 100% | 3h - 80% | 2,5h - 50% with charger EC-E8004 |
| Compatibility: | SHIMANO STEPS EP800, E8000, E7000, E6100, E6110, E5100, E5000 |
| Extras: | Compatible charging adapter - SM-BTE80 | Compatible battery holder - BM-E8030-A | BM-E8030-B | BM-E8031-A | BM-E8031-B |
| Item: | Shimano STEPS frame battery BT-E8016 |
| Manufacturer: | Shimano |
| Mounting: | inside the down tube |
| Scope of delivery: | 1x battery BT-E8016 |
| Shimano System: | Shimano E6000, Shimano E8000, Shimano Steps E5000, Shimano Steps E7000 (E-MTB), Shimano Steps EP8 |
| Specifications: | ON/OFF switch | charge indicator | ERROR signal |
| Weight: | approx. 3700g |
